Data stored for each collimator per event. More...
#include <BDSOutputROOTEventCollimator.hh>
Public Member Functions | |
BDSOutputROOTEventCollimator () | |
Default constructor for ROOT. | |
void | Fill (const BDSHitCollimator *hit, const BDSOutputROOTEventCollimatorInfo &info, const std::pair< G4double, G4double > &differences, G4bool storeHits) |
void | FillExtras (G4bool fillIonInfo, G4bool fillLinks) |
void | SetPrimaryStopped (G4bool primaryStoppedIn) |
Setter for one off flag per event. | |
void | Fill (const BDSOutputROOTEventCollimator *other) |
Copy data from another instance into this one. | |
virtual void | Flush () |
Flush this instance. | |
ClassDef (BDSOutputROOTEventCollimator, 1) | |
Data Fields | |
bool | primaryInteracted |
bool | primaryStopped |
int | n |
std::vector< float > | energy |
Total energy of particle for each hit. | |
std::vector< float > | energyDeposited |
std::vector< float > | xIn |
std::vector< float > | yIn |
std::vector< float > | zIn |
std::vector< float > | xpIn |
std::vector< float > | ypIn |
std::vector< float > | zpIn |
std::vector< float > | T |
std::vector< float > | weight |
std::vector< int > | partID |
std::vector< int > | parentID |
std::vector< int > | turn |
std::vector< bool > | firstPrimaryHitThisTurn |
std::vector< float > | impactParameterX |
std::vector< float > | impactParameterY |
std::vector< bool > | isIon |
std::vector< int > | ionA |
std::vector< int > | ionZ |
std::set< int > | turnSet |
Different length set of turn number. | |
double | totalEnergyDeposited |
Sum of energy deposits including weights. | |
std::vector< int > | charge |
These are not filled by default. | |
std::vector< float > | kineticEnergy |
These are not filled by default. | |
std::vector< float > | mass |
These are not filled by default. | |
std::vector< float > | rigidity |
These are not filled by default. | |
Static Public Attributes | |
static BDSOutputROOTParticleData * | particleTable |
Data stored for each collimator per event.
Definition at line 42 of file BDSOutputROOTEventCollimator.hh.
|
virtual |
Definition at line 51 of file BDSOutputROOTEventCollimator.cc.
void BDSOutputROOTEventCollimator::Fill | ( | const BDSHitCollimator * | hit, |
const BDSOutputROOTEventCollimatorInfo & | info, | ||
const std::pair< G4double, G4double > & | differences, | ||
G4bool | storeHits | ||
) |
Definition at line 87 of file BDSOutputROOTEventCollimator.cc.
void BDSOutputROOTEventCollimator::Fill | ( | const BDSOutputROOTEventCollimator * | other | ) |
Copy data from another instance into this one.
Definition at line 218 of file BDSOutputROOTEventCollimator.cc.
References charge, energy, firstPrimaryHitThisTurn, kineticEnergy, mass, rigidity, and turnSet.
void BDSOutputROOTEventCollimator::FillExtras | ( | G4bool | fillIonInfo, |
G4bool | fillLinks | ||
) |
Definition at line 167 of file BDSOutputROOTEventCollimator.cc.
|
virtual |
Flush this instance.
Definition at line 54 of file BDSOutputROOTEventCollimator.cc.
References charge, energy, firstPrimaryHitThisTurn, kineticEnergy, mass, rigidity, totalEnergyDeposited, and turnSet.
|
inline |
Setter for one off flag per event.
Definition at line 99 of file BDSOutputROOTEventCollimator.hh.
std::vector<int> BDSOutputROOTEventCollimator::charge |
These are not filled by default.
Definition at line 81 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::energy |
Total energy of particle for each hit.
Definition at line 51 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::energyDeposited |
Definition at line 52 of file BDSOutputROOTEventCollimator.hh.
std::vector<bool> BDSOutputROOTEventCollimator::firstPrimaryHitThisTurn |
A primary can generate multiple hits on a single passage through a collimator, but we're most interested in the first one where it impacted, so this is a flag for that hit. The same primary may hit on subsequent turns (however unlikely) in a ring so we must do this each turn.
Definition at line 68 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::impactParameterX |
Definition at line 70 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::impactParameterY |
Definition at line 71 of file BDSOutputROOTEventCollimator.hh.
std::vector<int> BDSOutputROOTEventCollimator::ionA |
Definition at line 74 of file BDSOutputROOTEventCollimator.hh.
std::vector<int> BDSOutputROOTEventCollimator::ionZ |
Definition at line 75 of file BDSOutputROOTEventCollimator.hh.
std::vector<bool> BDSOutputROOTEventCollimator::isIon |
Definition at line 73 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::kineticEnergy |
These are not filled by default.
Definition at line 82 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::mass |
These are not filled by default.
Definition at line 83 of file BDSOutputROOTEventCollimator.hh.
int BDSOutputROOTEventCollimator::n |
Definition at line 50 of file BDSOutputROOTEventCollimator.hh.
std::vector<int> BDSOutputROOTEventCollimator::parentID |
Definition at line 62 of file BDSOutputROOTEventCollimator.hh.
|
static |
Definition at line 108 of file BDSOutputROOTEventCollimator.hh.
std::vector<int> BDSOutputROOTEventCollimator::partID |
Definition at line 61 of file BDSOutputROOTEventCollimator.hh.
bool BDSOutputROOTEventCollimator::primaryInteracted |
Definition at line 48 of file BDSOutputROOTEventCollimator.hh.
bool BDSOutputROOTEventCollimator::primaryStopped |
Definition at line 49 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::rigidity |
These are not filled by default.
Definition at line 84 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::T |
Definition at line 59 of file BDSOutputROOTEventCollimator.hh.
double BDSOutputROOTEventCollimator::totalEnergyDeposited |
Sum of energy deposits including weights.
Definition at line 87 of file BDSOutputROOTEventCollimator.hh.
Referenced by Flush().
std::vector<int> BDSOutputROOTEventCollimator::turn |
Definition at line 63 of file BDSOutputROOTEventCollimator.hh.
std::set<int> BDSOutputROOTEventCollimator::turnSet |
Different length set of turn number.
Definition at line 78 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::weight |
Definition at line 60 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::xIn |
Definition at line 53 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::xpIn |
Definition at line 56 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::yIn |
Definition at line 54 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::ypIn |
Definition at line 57 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::zIn |
Definition at line 55 of file BDSOutputROOTEventCollimator.hh.
std::vector<float> BDSOutputROOTEventCollimator::zpIn |
Definition at line 58 of file BDSOutputROOTEventCollimator.hh.
