BDSIM is a Geant4 extension toolkit for simulation of particle transport in accelerator beamlines.
|
Class to store all options for a BDSIM run. More...
#include <BDSOutputROOTEventOptions.hh>
Public Member Functions | |
BDSOutputROOTEventOptions (const GMAD::OptionsBase *ob) | |
void | Fill () |
ClassDef (BDSOutputROOTEventOptions, 7) | |
![]() | |
OptionsBase () | |
void | print () const |
print some properties | |
Additional Inherited Members | |
![]() | |
std::string | inputFileName |
Input filename. | |
std::string | visMacroFileName |
Visualisation filename. | |
std::string | geant4MacroFileName |
Geant4 macro to run. | |
std::string | geant4PhysicsMacroFileName |
Geant4 physics macro. | |
bool | geant4PhysicsMacroFileNameFromExecOptions |
bool | visDebug |
Flag for visualisation debug. | |
bool | batch |
Flag for batch / interactive mode. | |
bool | verbose |
General verbosity. | |
int | verboseRunLevel |
Run level verbosity. | |
int | verboseTrackingLevel |
Tracking verbosity. | |
int | verboseImportanceSampling |
bool | verboseSensitivity |
bool | circular |
Flag for circular machine. | |
int | seed |
The seed value for the random number generator. | |
std::string | randomEngine |
Name of random engine to use. | |
int | nGenerate |
The number of primary events to simulate. | |
bool | recreate |
Whether to recreate from a file or not. | |
std::string | recreateFileName |
The file path to recreate a run from. | |
int | startFromEvent |
Event to start from when recreating. | |
bool | writeSeedState |
Write the seed state each event to a text file. | |
bool | useASCIISeedState |
Whether to use the seed state from an ASCII file. | |
std::string | seedStateFileName |
Seed state file path. | |
bool | generatePrimariesOnly |
Whether to only generate primary coordinates and quit, or not. | |
std::string | bdsimPath |
std::string | physicsList |
list of physics processes | |
bool | physicsVerbose |
int | physicsVerbosity |
double | physicsEnergyLimitLow |
double | physicsEnergyLimitHigh |
bool | g4PhysicsUseBDSIMRangeCuts |
bool | g4PhysicsUseBDSIMCutsAndLimits |
int | eventOffset |
Event number to start from when recreating from a root file. | |
bool | recreateSeedState |
Load seed state when recreating events. | |
double | elossHistoBinWidth |
double | ffact |
magnetic field flip (+1 default, -1: flip sign) | |
int | eventNumberOffset |
bool | checkOverlaps |
bdsim options | |
double | xsize |
for element specification | |
double | ysize |
std::string | magnetGeometryType |
default magnet geometry parameters | |
std::string | outerMaterialName |
double | horizontalWidth |
double | thinElementLength |
bool | hStyle |
H Style dipoles (if not, C Style). | |
double | vhRatio |
double | coilWidthFraction |
double | coilHeightFraction |
bool | ignoreLocalMagnetGeometry |
bool | buildPoleFaceGeometry |
bool | preprocessGDML |
geometry control | |
bool | preprocessGDMLSchema |
bool | dontSplitSBends |
geometry debug, don't split bends into multiple segments | |
bool | yokeFields |
bool | yokeFieldsMatchLHCGeometry |
bool | useOldMultipoleOuterFields |
double | scalingFieldOuter |
bool | includeFringeFields |
bool | includeFringeFieldsCavities |
std::string | vacMaterial |
vacuum material | |
std::string | emptyMaterial |
material in container volumes | |
std::string | worldMaterial |
std::string | worldGeometryFile |
bool | autoColourWorldGeometryFile |
std::string | importanceWorldGeometryFile |
std::string | importanceVolumeMap |
double | worldVolumeMargin |
Padding margin for world volume size. | |
double | vacuumPressure |
bool | removeTemporaryFiles |
std::string | temporaryDirectory |
double | samplerDiameter |
std::string | defaultBiasVacuum |
std::string | defaultBiasMaterial |
std::string | biasForWorldVolume |
std::string | biasForWorldContents |
std::string | biasForWorldVacuum |
std::string | worldVacuumVolumeNames |
std::string | integratorSet |
std::string | fieldModulator |
double | lengthSafety |
double | lengthSafetyLarge |
double | maximumTrackingTime |
Maximum tracking time per track [s]. | |
double | maximumStepLength |
Maximum permitted step length in any volume. | |
double | maximumTrackLength |
Maximum permitted track length [m]. | |
double | chordStepMinimum |
double | chordStepMinimumYoke |
double | deltaIntersection |
double | minimumEpsilonStep |
double | maximumEpsilonStep |
double | deltaOneStep |
bool | stopSecondaries |
bool | killNeutrinos |
bool | killedParticlesMassAddedToEloss |
double | minimumRadiusOfCurvature |
Minimum allowed radius of curvature. | |
bool | sampleElementsWithPoleface |
double | nominalMatrixRelativeMomCut |
Momentum threshold for nominal dipole matrix tracking. | |
bool | teleporterFullTransform |
Whether to use the new Transform3D method for the teleporter. | |
double | dEThresholdForScattering |
double | backupStepperMomLimit |
Fractional momentum limit for reverting to backup steppers. | |
bool | sensitiveOuter |
bool | sensitiveBeamPipe |
int | numberOfEventsPerNtuple |
bool | storeMinimalData |
bool | storeApertureImpacts |
bool | storeApertureImpactsIons |
bool | storeApertureImpactsAll |
bool | storeApertureImpactsHistograms |
double | apertureImpactsMinimumKE |
bool | storeCavityInfo |
bool | storeCollimatorInfo |
bool | storeCollimatorHits |
bool | storeCollimatorHitsLinks |
bool | storeCollimatorHitsIons |
bool | storeCollimatorHitsAll |
double | collimatorHitsMinimumKE |
bool | storeEloss |
bool | storeElossHistograms |
bool | storeElossVacuum |
bool | storeElossVacuumHistograms |
bool | storeElossTunnel |
bool | storeElossTunnelHistograms |
bool | storeElossWorld |
bool | storeElossWorldIntegral |
bool | storeElossWorldContents |
bool | storeElossWorldContentsIntegral |
bool | storeElossTurn |
bool | storeElossLinks |
bool | storeElossLocal |
bool | storeElossGlobal |
bool | storeElossTime |
bool | storeElossStepLength |
bool | storeElossPreStepKineticEnergy |
bool | storeElossModelID |
bool | storeElossPhysicsProcesses |
bool | storeParticleData |
bool | storePrimaries |
bool | storePrimaryHistograms |
bool | storeTrajectory |
int | storeTrajectoryDepth |
int | storeTrajectoryStepPoints |
bool | storeTrajectoryStepPointLast |
std::string | storeTrajectoryParticle |
std::string | storeTrajectoryParticleID |
bool | storeTrajectorySecondaryParticles |
double | storeTrajectoryEnergyThreshold |
std::string | storeTrajectorySamplerID |
std::string | storeTrajectoryELossSRange |
bool | storeTrajectoryTransportationSteps |
bool | trajNoTransportation |
kept only for backwards compatibility. | |
bool | storeTrajectoryKineticEnergy |
bool | storeTrajectoryMomentumVector |
bool | storeTrajectoryProcesses |
bool | storeTrajectoryTime |
bool | storeTrajectoryLocal |
bool | storeTrajectoryLinks |
bool | storeTrajectoryIon |
bool | storeTrajectoryMaterial |
bool | storeTrajectoryAllVariables |
bool | trajectoryFilterLogicAND |
bool | storeSamplerAll |
bool | storeSamplerPolarCoords |
bool | storeSamplerCharge |
bool | storeSamplerKineticEnergy |
bool | storeSamplerMass |
bool | storeSamplerRigidity |
bool | storeSamplerIon |
double | trajCutGTZ |
double | trajCutLTR |
bool | trajConnect |
bool | storeModel |
int | samplersSplitLevel |
int | modelSplitLevel |
int | uprootCompatible |
int | nturns |
std::string | ptcOneTurnMapFileName |
double | printFractionEvents |
double | printFractionTurns |
bool | printPhysicsProcesses |
int | nSegmentsPerCircle |
Number of facets per 2pi in visualisation. | |
int | nbinsx |
int | nbinsy |
int | nbinsz |
int | nbinse |
double | xmin |
double | xmax |
double | ymin |
double | ymax |
double | zmin |
double | zmax |
double | emin |
double | emax |
bool | useScoringMap |
std::vector< std::string > | setKeys |
A list of all the keys that have been set in this instance. | |
std::string | outputFileName |
Parameter for output format. | |
std::string | outputFormat |
Parameter for output format. | |
bool | outputDoublePrecision |
Parameter for output format. | |
int | outputCompressionLevel |
Parameter for output format. | |
bool | survey |
Parameter for survey. | |
std::string | surveyFileName |
Parameter for survey. | |
bool | verboseEventBDSIM |
Event level verbosity. | |
int | verboseEventLevel |
Event level verbosity. | |
int | verboseEventStart |
Event level verbosity. | |
int | verboseEventContinueFor |
Event level verbosity. | |
bool | verboseSteppingBDSIM |
Stepping level verbosity. | |
int | verboseSteppingLevel |
Stepping level verbosity. | |
int | verboseSteppingEventStart |
Stepping level verbosity. | |
int | verboseSteppingEventContinueFor |
Stepping level verbosity. | |
bool | verboseSteppingPrimaryOnly |
Stepping level verbosity. | |
bool | exportGeometry |
Parameter for controlling geometry export. | |
std::string | exportType |
Parameter for controlling geometry export. | |
std::string | exportFileName |
Parameter for controlling geometry export. | |
double | beamlineX |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineY |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineZ |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlinePhi |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineTheta |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlinePsi |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineAxisX |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineAxisY |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineAxisZ |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineAngle |
Initial beam line transform w.r.t. the world coordinate frame. | |
bool | beamlineAxisAngle |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beamlineS |
Initial beam line transform w.r.t. the world coordinate frame. | |
double | beampipeThickness |
default beampipe parameters | |
std::string | apertureType |
default beampipe parameters | |
double | aper1 |
default beampipe parameters | |
double | aper2 |
default beampipe parameters | |
double | aper3 |
default beampipe parameters | |
double | aper4 |
default beampipe parameters | |
std::string | beampipeMaterial |
default beampipe parameters | |
bool | ignoreLocalAperture |
default beampipe parameters | |
bool | buildTunnel |
tunnel geometry parameters | |
bool | buildTunnelStraight |
tunnel geometry parameters | |
std::string | tunnelType |
tunnel geometry parameters | |
double | tunnelThickness |
tunnel geometry parameters | |
double | tunnelSoilThickness |
tunnel geometry parameters | |
std::string | tunnelMaterial |
tunnel geometry parameters | |
std::string | soilMaterial |
tunnel geometry parameters | |
bool | buildTunnelFloor |
tunnel geometry parameters | |
double | tunnelFloorOffset |
tunnel geometry parameters | |
double | tunnelAper1 |
tunnel geometry parameters | |
double | tunnelAper2 |
tunnel geometry parameters | |
bool | tunnelVisible |
tunnel geometry parameters | |
double | tunnelOffsetX |
tunnel geometry parameters | |
double | tunnelOffsetY |
tunnel geometry parameters | |
double | tunnelMaxSegmentLength |
tunnel geometry parameters | |
bool | turnOnOpticalAbsorption |
Physics processes. | |
bool | turnOnMieScattering |
Physics processes. | |
bool | turnOnRayleighScattering |
Physics processes. | |
bool | turnOnOpticalSurface |
Physics processes. | |
double | scintYieldFactor |
physics parameters | |
int | maximumPhotonsPerStep |
physics parameters | |
int | maximumBetaChangePerStep |
physics parameters | |
long | maximumTracksPerEvent |
physics parameters | |
double | minimumKineticEnergy |
physics parameters | |
double | minimumKineticEnergyTunnel |
physics parameters | |
double | minimumRange |
physics parameters | |
std::string | particlesToExcludeFromCuts |
physics parameters | |
double | defaultRangeCut |
physics parameters | |
double | prodCutPhotons |
physics parameters | |
double | prodCutElectrons |
physics parameters | |
double | prodCutPositrons |
physics parameters | |
double | prodCutProtons |
physics parameters | |
double | neutronTimeLimit |
physics parameters | |
double | neutronKineticEnergyLimit |
physics parameters | |
bool | useLENDGammaNuclear |
physics parameters | |
bool | useElectroNuclear |
physics parameters | |
bool | useMuonNuclear |
physics parameters | |
bool | useGammaToMuMu |
physics parameters | |
bool | usePositronToMuMu |
physics parameters | |
bool | usePositronToHadrons |
physics parameters | |
bool | restoreFTPFDiffractionForAGreater10 |
physics parameters | |
bool | beamPipeIsInfiniteAbsorber |
physics parameters | |
bool | collimatorsAreInfiniteAbsorbers |
physics parameters | |
bool | tunnelIsInfiniteAbsorber |
physics parameters | |
int | muonSplittingFactor |
physics parameters | |
double | muonSplittingThresholdParentEk |
physics parameters | |
int | muonSplittingFactor2 |
physics parameters | |
double | muonSplittingThresholdParentEk2 |
physics parameters | |
bool | muonSplittingExcludeWeight1Particles |
physics parameters | |
double | muonSplittingExclusionWeight |
physics parameters | |
Class to store all options for a BDSIM run.
Definition at line 33 of file BDSOutputROOTEventOptions.hh.
|
explicit |
Definition at line 27 of file BDSOutputROOTEventOptions.cc.
|
virtual |
Definition at line 30 of file BDSOutputROOTEventOptions.cc.
void BDSOutputROOTEventOptions::Fill | ( | ) |
Definition at line 34 of file BDSOutputROOTEventOptions.cc.
