Public Member Functions | |
| BDSRBend (G4String aName, G4double aLength, G4double bpRad, G4double FeRad, G4double bField, G4double angle, G4double outR, std::list< G4double > blmLocZ, std::list< G4double > blmLocTheta, G4double tilt=0, G4double bGrad=0, G4String aTunnelMaterial="", G4String aMaterial="") | |
| ~BDSRBend () | |
| void | SynchRescale (G4double factor) |
Private Member Functions | |
| void | BuildBPFieldAndStepper () |
| void | BuildRBMarkerLogicalVolume () |
| void | BuildRBBeampipe () |
| void | BuildRBOuterLogicalVolume (G4bool OuterMaterialIsVacuum=false) |
| G4VisAttributes * | SetVisAttributes () |
Private Attributes | |
| G4double | itsBField |
| G4double | itsBGrad |
| G4double | itsMagFieldLength |
| G4Trd * | markerSolidVolume |
| G4Trd * | rbendRectangleSolidVolume |
| G4LogicalVolume * | rbendRectangleLogicalVolume |
| G4LogicalVolume * | middleBeampipeLogicalVolume |
| G4LogicalVolume * | middleInnerBPLogicalVolume |
| G4LogicalVolume * | endsBeampipeLogicalVolume |
| G4LogicalVolume * | endsInnerBPLogicalVolume |
| G4UserLimits * | endsBeampipeUserLimits |
| G4UserLimits * | endsInnerBeampipeUserLimits |
| G4VisAttributes * | innerBeampipeVisAtt |
| G4VisAttributes * | beampipeVisAtt |
| myQuadStepper * | itsStepper |
| BDSSbendMagField * | itsMagField |
| G4Mag_EqRhs * | itsEqRhs |
Definition at line 28 of file BDSRBend.hh.
