Public Member Functions | |
| BDSAwakeMultilayerScreen (G4String material, G4double thickness, G4double dgrain, G4double windowThickness, G4String windowMaterial) | |
| virtual | ~BDSAwakeMultilayerScreen () |
| void | surfaces () |
| void | place (G4RotationMatrix *rot, G4ThreeVector pos, G4LogicalVolume *motherVol) |
Private Types | |
| typedef BDSMultilayerScreen | super |
Private Member Functions | |
| void | layers () |
| void | sampler (G4String name) |
| void | preWindowSampler () |
| void | preScreenSampler () |
| void | postScreenSampler () |
| void | windowLayer () |
| void | backLayer () |
| void | substrateLayer () |
| void | binderLayer () |
| void | backBinderLayer () |
| void | scintillatorLayer () |
| void | backScintillatorLayer () |
| void | frontScintillatorLayer1 () |
| void | frontScintillatorLayer2 () |
| void | frontLayer () |
| void | reflectiveSurface () |
| void | roughSurface () |
Private Attributes | |
| G4String | _material |
| G4double | _thickness |
| G4double | _gapWidth |
| G4double | _gapSpacing |
| G4double | _dgrain |
| G4double | _windowThickness |
| G4String | _windowMaterial |
| G4double | _layerThickness |
| G4double | _binderLayerThickness |
| G4double | _firstLayerThickness |
| G4double | _firstBinderLayerThickness |
| G4double | _nScintLayers |
| G4double | _fillFactor |
Definition at line 6 of file BDSAwakeMultilayerScreen.hh.
